<?xml version="1.0" encoding="UTF8"?>
<!DOCTYPE C-JDBC PUBLIC "-//ObjectWeb//DTD C-JDBC 2.0.2//EN" "http://c-jdbc.objectweb.org/dtds/c-jdbc-2.0.2.dtd">

<C-JDBC>

<VirtualDatabase name="myDB">

<Distribution>
</Distribution>

<AuthenticationManager>
<Admin>
<User username="admin" password="c-jdbc"/>
</Admin>
<VirtualUsers>
<VirtualLogin vLogin="boss" vPassword="boss"/>
</VirtualUsers>
</AuthenticationManager>

<DatabaseBackend name="mysqlNode211" driver="org.gjt.mm.mysql.Driver" url="jdbc:mysql://192.168.0.2/clusterdb" connectionTestStatement="select 1">
<ConnectionManager vLogin="boss" rLogin="boss_user" rPassword="123456">
<VariablePoolConnectionManager initPoolSize="10" minPoolSize="10" maxPoolSize="50" idleTimeout="30" waitTimeout="10"/>
</ConnectionManager>
</DatabaseBackend>

<DatabaseBackend name="mysqlNode213" driver="org.gjt.mm.mysql.Driver" url="jdbc:mysql://192.168.0.3/clusterdb" connectionTestStatement="select 1">
<ConnectionManager vLogin="boss" rLogin="boss_user" rPassword="123456">
<VariablePoolConnectionManager initPoolSize="10" minPoolSize="10" maxPoolSize="50" idleTimeout="30" waitTimeout="10"/>
</ConnectionManager>
</DatabaseBackend>

<RequestManager>
<RequestScheduler>
<RAIDb-1Scheduler level="passThrough"/>
</RequestScheduler>

<LoadBalancer>
<RAIDb-1>
<WaitForCompletion policy="first"/>
<RAIDb-1-LeastPendingRequestsFirst/>
</RAIDb-1>
</LoadBalancer>
</RequestManager>

</VirtualDatabase>

</C-JDBC>

<?xml version="1.0" encoding="UTF8" ?>
<!DOCTYPE C-JDBC-CONTROLLER PUBLIC "-//ObjectWeb//DTD C-JDBC-CONTROLLER 2.0.2//EN" "http://c-jdbc.objectweb.org/dtds/c-jdbc-controller-2.0.2.dtd">
<C-JDBC-CONTROLLER>
<Controller port="25323">
<JmxSettings>
<RmiJmxAdaptor port="1091"/>
</JmxSettings>
<VirtualDatabase configFile="mysql-raidb1-distribution.xml" virtualDatabaseName="myDB" autoEnableBackends="true"/>
</Controller>
</C-JDBC-CONTROLLER>

#!/bin/sh

export CJDBC_HOME=/usr/local/c-jdbc
export JAVA_HOME=/opt/jdk1.5

cd $CJDBC_HOME/bin

echo "Waiting for mysql servers to finish start up"

echo "Starting Controller"
./controller.sh -f ../config/controller/uud-controller-distributed.xml &

Waiting for mysql servers to finish start up
Starting Controller
2006-04-20 10:32:21,126 INFO controller.core.Controller C-JDBC controller (2.0.2)
2006-04-20 10:32:21,189 INFO controller.core.Controller Loading configuration file: ../config/controller/uud-controller-distributed.xml
2006-04-20 10:32:21,278 INFO controller.core.Controller JMX is enabled
2006-04-20 10:32:21,308 INFO controller.core.Controller Starting JMX server on host: 127.0.0.1
2006-04-20 10:32:21,674 INFO backend.DatabaseBackend.mysqlNode211 Adding connection manager for virtual user "boss"
2006-04-20 10:32:21,749 INFO backend.DatabaseBackend.mysqlNode213 Adding connection manager for virtual user "boss"
2006-04-20 10:32:21,809 INFO controller.RequestManager.myDB Request manager will parse requests with the following granularity: NO_PARSING
2006-04-20 10:32:21,814 INFO controller.virtualdatabase.myDB Configuring jgroups using: file:/usr/local/c-jdbc/config/jgroups.xml

-------------------------------------------------------
GMS: address is 127.0.0.1:32773
-------------------------------------------------------
2006-04-20 10:32:26,476 INFO controller.virtualdatabase.myDB Group myDB connected to /127.0.0.1:32773[/127.0.0.1:32773]
2006-04-20 10:32:26,476 INFO controller.virtualdatabase.myDB First controller in group myDB
2006-04-20 10:32:26,477 WARN controller.virtualdatabase.myDB No recovery log has been configured, enabling backend without checkpoint.

[1]+ Done ./uud-distributed-raidb1-controller.sh

/**
* @author 胡榮華
* @Company 世紀(jì)龍 21cn
*/
package com.cjdbc.test;

import java.sql.Connection;
import java.sql.PreparedStatement;
import java.sql.DriverManager;

/**
*
*/
public class GenerateSampleData {

public void generate() {
Connection conn = null;
PreparedStatement pstmt = null;
try {
// 這是 c-jdbc drivers 的 Drivers class，注意不是 mysql 的 Drivers class
Class.forName("org.objectweb.cjdbc.driver.Driver").newInstance();
// 192.168.0.1 是 cjdbc controller 所在的 ip
// myDB 是在 文件 mysql-raidb1-distribution.xml 里定義的 <VirtualDatabase name="myDB">
// user=boss&password=boss 是在 文件 mysql-raidb1-distribution.xml 里定義的
// <VirtualUsers>
// <VirtualLogin vLogin="boss" vPassword="boss"/>
// </VirtualUsers>
String url = "jdbc:cjdbc://192.168.0.1:25323/myDB?user=boss&password=boss";

conn = DriverManager.getConnection(url);

try{
conn.setAutoCommit(false);
pstmt = conn.prepareStatement("insert into user values ('', ?)");

int numOfTestRecords = 10;
System.out.println("Update Record Start.");
for (int i=0;i<numOfTestRecords;i++) {
String newkey = i + "-" + i;
pstmt.setString(1, "hua_" + newkey);
pstmt.executeUpdate();

}
conn.commit();
System.out.println("Update Record Success.");
}
catch(Exception ex){
conn.rollback();
ex.printStackTrace();
}
finally{
try {
if( pstmt != null )
pstmt.close();
if( conn != null)
conn.close();
}
catch(Exception e) {
e.printStackTrace();
}
}
} catch (Exception e) {
e.printStackTrace();
}
}

/**
* @param args
*/
public static void main(String[] args) {
// TODO Auto-generated method stub
GenerateSampleData g = new GenerateSampleData();
g.generate();

}

}
